50 Ton Tipper Trailer 3 Axle for Heavy-Duty Transport Needs
50 Ton Tipper Trailer 3 Axle Description
Our 50 Ton Tipper Trailer is designed for heavy-duty transport, capable of carrying large amounts of materials like ore, sand, and construction debris. The 3-axle configuration ensures stability and a smooth ride under heavy loads. Equipped with a WABCO air braking system, this China dump semi trailer is safe, durable, and ideal for mining, construction, and agricultural transportation.
Key Features
- Heavy-Duty Construction: Crafted with high-strength steel, the 50 Ton Tipper Trailer ensures superior durability and resistance to wear, making it suitable for handling heavy loads and working in demanding environments.
- Powerful Hydraulic System: Equipped with branded hydraulic cylinders, this trailer features efficient tipping, allowing for fast unloading without residue. The system is designed for long-lasting performance with excellent lifting force and sealing.
- Customizable Load Capacity: With a load range from 30 tons to 100 tons, this trailer can be tailored to your specific transport needs. The configuration of axles (2, 3, 4, or 5) ensures stability under various load conditions.
Versatile Applications
- Ore and Mineral Transport: Perfect for transporting ores like bauxite and iron, the trailer’s rear tipping mechanism allows for quick unloading, which is essential for mining operations.
- Construction Material Transport: Efficiently moves bulk materials such as sand, gravel, cement, and coal, ensuring that unloading is done quickly and efficiently, reducing downtime on job sites.
- Agricultural Transportation: Ideal for transporting agricultural products like grains, fertilizers, and feed. The cargo box options (U-type or rectangular) ensure easy unloading of bulk agricultural materials.
50 Ton Tipper Trailer 3 Axle Parameters
| Brand | ROADKING |
| Application | Coal/Mine/Stand/Stone Loading |
| Dump Style | Rear Dump |
| Loading Capacity | 30T-100T |
| Axle | 2/3/4 * 13/16T, VEHICLE MASTER/FUWA/BPW |
| Length | 11000mm |
| Width | 2500mm |
| Height | 2800mm |
| Cylinder | HYVA (model according to the length of cargo box) |
| Floor Plate Thickness | 5mm |
| Cargo Thickness | 4mm |
| Cargo Style | Rectangular/Round |
| Front Axle Lifting | Available |
| Main Beam Material | Q345/T700 |
| Main Beam Height | 500mm |
| Upper Plate Thickness | 14mm |
| Middle Plate Thickness | 8mm |
| Lower Plate Thickness | 16mm |
| Tire | 11.00R20/12R22.5 * 8/12/16 pieces, Linglong/Triangle/Double-Coin/Bridgestone |
| Rim | 8.0/9.0 * 8/12/16 pieces, steel/aluminum |
| Suspension | Mechanical/Airbag |
| Leaf Spring | 90mm * 13/16mm * 10 pieces |
| Landing Gear | 28T two-speed, JOST |
| King Pin | #50(2")/#90(3.5"), JOST/Other Brand |
| Tool Box | Steel/aluminum |
Specifications
| Specification | Details |
| Model | 3 Axle 50 Ton Tipper Trailer |
| Rated Load | 50 tons |
| Customizable Load | 30–100 tons |
| Axles | 3 axles (2/4/5 axles customizable) |
| Axle Configuration | 13/16 tons per axle, FUWA/BPW, front axle lifting supported |
| Cargo Box Material | High-strength carbon steel |
| Cargo Box Shape | U-type / Rectangular (optional) |
| Dumping Type | Rear tipping |
| Cylinder | HYVA (model according to the length of cargo box) |
| Braking System | WABCO air braking |
| Suspension System | Mechanical suspension / Air suspension |
| Tires | 11.00R20 / 12R22.5 |
| Tire Quantity | 12 tires for 3 axles, 4 tires per axle |
| Landing Gear | 28T two-speed, JOST |
| King Pin | #50 (2") / #90 (3.5"), JOST / Other Brand |
Durability and Efficiency
- Reliable Suspension System: The trailer is equipped with either mechanical or air suspension systems, which provide enhanced stability and smooth operation, even on rough terrain.
- Tires Built for Tough Conditions: The 50 Ton Tipper Trailer comes with high-quality tires, ensuring excellent traction and wear resistance, making it perfect for challenging roads and varied working conditions.
- Advanced Braking System: The trailer features a WABCO air braking system for effective stopping power, increasing safety during transportation.
Customization and Pricing
We offer full customization options, allowing you to select the right load capacity, axle configuration, and cargo box style to match your specific operational needs. The 3 Axle 50 Tipper trailer made in China is priced competitively, ensuring you get great value for your investment while meeting the demands of your transport business.
